Double System Computerized Flat Knitting Machine
1. The fast cornering of carriage. Superior servo drive assembly makes the fast cornering of carriage came true, improved the efficiency of knitting more than 10%.
2. Well-designed angle of needle bed tooth mouth to ensure rapid autonomous falling of fabrics.
3. Duplex table technique of thick needle, fulfilling double distance and expanding table scope significantly.
4. Triangle baseboard, adopting precise forging materials with the most superior quality, some are produced by Taiwan manufacturer according to our brand new design program with optimized degree of surface pressure, making surface of fabrics more even, density more proper and knitting more smooth.model WTJX-2-52 Gague 3G, 3.5G,3-5-7G, 5G,6G, 7G, 8G, 9G, 10G,12G, 13G, 14G, 15G Knitting system double system,single carriage knitting width 44, 52, 60, 80, 100 inch knitting speed max 1.2m/s knitting function tranfer tuck, miss jacquard intarsia hide or apparent shaping sitch density Stitch system controlled by stepping motor, 32 section stitch selectable, adjustable scope supported by subdivision technology: 0-650. racking Controlled by AC servo motor, racking within 2 inches and with fine adjustiing function driving system Synchronous belt drive, AC servo system. needle section Controlled by computer, electric magnet needle caoose system with high efficiency. scissor&clamp Including 2 scissor and 4 damps, which individually controlled by 6 motors separately, located the both of needle bed separately, further to increase the work efficiency and to reduce yarn consumption. yarn carrier 2*8 yarn carriers on each side of 4 guide rails, shiftable on any needle position. take down roller Programmed instruction controlled by stepping motor, 32 section levels selection adjustable area: 0- 100 sinker system Assist knitting, have various results of shaping and stop. protection system The machine will automatically alarm if yarn breaking, float yarn, rewindiend of knitting, fail of racking, needle breakage and error programming occur, ect. contral system 1, Adopt LCD screen, input device: USB, system memory 256MB, a great amount of design files can be stored. 2, Monitoring menu, each kind of operating parameter, can be shown, and they can be adjusted at any time when the machine is running. 3, Design system is visual and easy to understand and upgrad. 4, Multi language version, there are Chinese, english etc. power 220v, single-phase, have memorizing function at :he power-off moment
